100V input, 1.5A output, asynchronous buck converter
Model No. :
CX8802Withstand voltage :
100VOutput voltage :
ADJOutput current :
1.5AWorking mode :
asynchronousPackaging :
ESOP-8100V input, 1.5A output, asynchronous buck converter
Summary:
CX8802 is an asynchronous buck converter with a wide range input voltage of 9V to 100V.
The CX8802 integrates a 120V 400-m Ω high-voltage side MOSFET with built-in compensation for fixed frequency peak current control, eliminating the need for external components.
The CX8802 provides a continuous load current of 1.5A, with an efficiency of up to 95%. The cycle by cycle current limit of high-end MOSFETs can protect the converter in case of overload. If the overcurrent condition lasts longer than the current time, it triggers burp mode protection.
CX8802 has a protection function that can protect the load from faults such as undervoltage, overcurrent, and overheating.
Features:
Input voltage range from 9V to 100V
1.5A current limit
1A continuous load current
95% peak efficiency
400uA working static current
120V 400-m Ω high-voltage side MOSFET
Peak current mode control
150kHz fixed frequency
Easy to use internal compensation
Up to 92% duty cycle
0.8V voltage reference
1 µ A off current
Short circuit protection function in 150ms burping mode
Thermal shutdown function
ESOP-8 Packaging
Application:
Car charger
Battery charger
The power adapter
